XS series sand washing machine production line is usually composed of feeders, crushers, drum screens, water washing wheels, belt conveyors,centralized electrical control and other equipment.
1.The structure of the machine is simple, and the impeller drive bearing device is isolated from water and water-receiving materials,which greatly avoids the damage of the bearing.
2. There is very little loss of medium-fine sand and stone powder, and the grade and fineness modulus of the washed building sand meet the standards for building sand,building pebbles, and gravel.
3. The machine has almost no wearing parts.
4. Long service life, no maintenance for a long time.
Model | Dia.of Wheel(mm) | Rotation Speed(r/min) | Capacity(t/h) | Motor Power(kw) | Weight(t) |
XS2612 | 2600 | 0.8-1.2 | 20-50 | 5.5 | 2.4 |
XS2816 | 2800 | 0.8-1.2 | 50-100 | 7.5 | 3 |
XS3218 | 3200 | 0.8-1.2 | 80-120 | 11 | 11.4 |
